Urkitchen | SUN-10K-SG05LP3-EU-SM2 | 10kW | Hybrid LV Inverter | 3-Phase | 2 MPPT

Technical details
Producer – Deye
Model – SUN-10K-SG05LP3-EU-SM2
MPN – SUN-10K-SG05LP3-EU-SM2
EAN – 2000001411810
Product Line – Hybrid Series (Low Voltage)
Product Type – Three-Phase Hybrid Inverter

Performance
Nominal output Power (AC) – 10000 W (10 kW)
Max. PV input Power (DC) – 13000 Wp
Max. PV input voltage – 800 V
Number of MPPTs – 2 (2+1 strings)
Max. Efficiency – 97.6%
Euro Efficiency – 97.0%
Battery Voltage Range – 40–60 V (Low Voltage)
Max. Charge/Discharge Current – 210 A

Features
Battery Compatibility – Lead-acid or Lithium-ion (48V system)
Smart Load – Dedicated port for generator or frequency-shifting applications
Parallel Capability – Supports up to 10 units in parallel (on-grid/off-grid)
Protection – IP65, DC/AC Type II SPD, AFCI protection
Interface – Colorful touch LCD for advanced monitoring and control

Dimensions & Weight
Product dimensions – 65.8 x 42.2 x 28.1 cm
Weight (device) – 35.2 kg

Shipping Box
Dimensions – 87 x 54 x 38 cm
Weight – 37.2 kg
